Raritan - Raritan PX3-1106X2-V2
Power distribution unit (rack-mountable) - AC 208 V - 34600 VA - 3-phase - RS-232, Ethernet 10/100/1000 - input: IEC 60309 3P+E - output connectors: 12 (IEC 60320 C19) - 0U - 10 ft cord - black powder coat
Raritan
PX3-1106X2-V2
N/A
0785813106322
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Raritan PX3-1106X2-V2 - power distribution unit - 34600 VA |
| Device Type | Power distribution unit - rack-mountable |
| Cord Length | 10 ft |
| Rack Size | 0U |
| Weight | 43.43 lbs |
| Input Wiring | 3-phase |
| Input Voltage | AC 208 V |
| Output Voltage | AC 208 V |
| Power Capacity | 34600 VA |
| Power Capacity Details | 34.6 kVA at 208 V, 39.9 kVA at 240 V |
| Input Connectors | 2 x power IEC 60309 3P+E |
| Output connectors | 12 x power IEC 60320 C19 16 A |
| Networking | RS-232, Ethernet 10/100/1000 |
| Remote Management Protocol | SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, JSON-RPC, SMTP, Modbus |
| Color | Black powder coat |
| Dimensions (WxDxH) | 2.3 in x 4.7 in x 72 in |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Power distribution unit - rack-mountable |
| Height (Rack Units) | 0U |
| Cord Length | 10 ft |
| Color | Black powder coat |
| Expansion / Connectivity | |
| Interfaces | 1 x console/modem - RJ-45 ¦ 1 x expansion - RJ-45 ¦ 1 x feature - RJ-45 ¦ 1 x sensor - RJ-45 ¦ 2 x management (Gigabit Ethernet) - RJ-45 ¦ 2 x USB - 4 pin USB Type A ¦ 1 x USB - 4 pin USB Type B |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 2 x power cable - integrated - 10 ft |
| Features | Vertical orientation, tool-less button mount, LCD display, voltage monitoring, current meter, cascadable, active power meter, real power meter, energy meter, power factor meter, Raritan SecureLock Ready, metering per input line, metering per branch circuit breaker, ISO/IEC 62053-21 1% metering accuracy, power cable IP67 compliant, cord retention, removable controller, bottom-front feed cord entry, environmental sensor ready, 12 x LEJBX66-20 overload protection |
| Compliant Standards | UL, ICES-003, RoHS, FCC Part 15 A, cULus |
| Networking | |
| Remote Management Interface | RS-232, Ethernet 10/100/1000 |
| Remote Management Protocol | SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, JSON-RPC, SMTP, Modbus |
| Environmental Parameters | |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 85% |
| Power Device | |
| Input Voltage | AC 208 V |
| Input Voltage Range | AC 208 - 240 V |
| Input Wiring | 3-phase |
| Frequency Required | 50/60 Hz |
| Input Connectors | 2 x power IEC 60309 3P+E |
| Power Output Connectors Details | 12 x power IEC 60320 C19 16 A |
| Output Voltage | AC 208 V |
| Max Electric Current | 60 A |
| Power Capacity | 34600 VA |
| Power Capacity Details | 34.6 kVA at 208 V, 39.9 kVA at 240 V |
| Dimensions & Weight | |
| Width | 2.3 in |
| Depth | 4.7 in |
| Height | 72 in |
| Weight | 43.43 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 18.3 in |
| Shipping Depth | 8.3 in |
| Shipping Height | 79.1 in |
| Shipping Weight | 53.79 lbs |
