Raritan - Raritan PX intelligent PX2-2085U-O1
Power distribution unit (rack-mountable) - AC 415 V - 17300 VA - 3-phase WYE (star) - Ethernet 10/100, RS-232, USB - input: NEMA L22-30P - output connectors: 48 (36 x IEC 60320 C13, 12 x IEC 60320 C19) - 0U - 10 ft cord - black powder coat
Raritan
PX2-2085U-O1
N/A
N/A
N/A
New
Product Description
Additional Details
What's Included
Main Specifications | |
---|---|
Product Description | Raritan PX intelligent PX2-2085U-O1 - power distribution unit - 17300 VA |
Device Type | Power distribution unit - rack-mountable |
Cord Length | 10 ft |
Rack Size | 0U |
Input Wiring | 3-phase WYE (star) |
Input Voltage | AC 415 V |
Output Voltage | AC 208 V |
Power Capacity | 17300 VA |
Power Capacity Details | 15 kVA at 360 V, 17.3 kVA at 415 V |
Input Connectors | 1 x power NEMA L22-30P |
Output connectors | 36 x power IEC 60320 C13 - 208 V 12 A ¦ 12 x power IEC 60320 C19 - 208 V 16 A |
Networking | Ethernet 10/100, RS-232, USB |
Remote Management Protocol | SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, JSON-RPC, SMTP, Modbus |
Color | Black powder coat |
Dimensions (WxDxH) | 3.5 in x 2.6 in x 70.1 in |
Manufacturer Warranty | 2-year warranty |
General | |
Device Type | Power distribution unit - rack-mountable |
Height (Rack Units) | 0U |
Cord Length | 10 ft |
Color | Black powder coat |
Expansion / Connectivity | |
Interfaces | 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x sensor ¦ 1 x USB - 4 pin USB Type B ¦ 1 x USB - 4 pin USB Type A ¦ 1 x monitoring ¦ 1 x management (Fast Ethernet) - RJ-45 |
Manufacturer Warranty | |
Service & Support | Limited warranty - 2 years |
Miscellaneous | |
Cables Included | Power cable - integrated - 10 ft |
Rack Mounting Kit | Included |
Features | LCD display, voltage monitoring, current meter, overload protection, cascadable, active power meter, real power meter, energy meter, power factor meter, Raritan SecureLock Ready, metering per input line, metering per branch circuit breaker, metering per output receptacle, cord retention outlet, power cable IP44 compliant |
Compliant Standards | UL, cUL, ICES-003, RoHS, FCC Part 15 A |
Networking | |
Remote Management Interface | Ethernet 10/100, RS-232, USB |
Remote Management Protocol | SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, JSON-RPC, SMTP, Modbus |
Environmental Parameters | |
Max Operating Temperature | 140 °F |
Humidity Range Operating | 85% |
Power Device | |
Input Voltage | AC 415 V |
Input Voltage Range | AC 360 - 415 V |
Input Wiring | 3-phase WYE (star) |
Frequency Required | 50/60 Hz |
Input Connectors | 1 x power NEMA L22-30P |
Power Output Connectors Details | 36 x power IEC 60320 C13 - 208 V 12 A ¦ 12 x power IEC 60320 C19 - 208 V 16 A |
Output Voltage | AC 208 V |
Max Electric Current | 30 A |
Power Capacity | 17300 VA |
Power Capacity Details | 15 kVA at 360 V, 17.3 kVA at 415 V |
Circuit Protection | Circuit breaker |
Dimensions & Weight | |
Width | 3.5 in |
Depth | 2.6 in |
Height | 70.1 in |
Dimensions & Weight (Shipping) | |
Shipping Width | 19.7 in |
Shipping Depth | 6.3 in |
Shipping Height | 88.2 in |
